Panasonic connector - Provide product overview of Panasonic AXK5S50047YG connector
 | Manufacturer | Panasonic |
| Manufacturer Part Number | AXK5S50047YG | |
| Product Description | CONN SOCKET 50POS SMD GOLD, 50 position connector socket, central contact with surface mount type gold plated |
Panasonic connector - Provide product attributes for Panasonic AXK5S50047YG connector
| Type | Description |
| Category | Connector, interconnection device |
| Rectangular connector | |
| Array, edge type, sandwich type (board-to-board) | |
| Manufacturer | Panasonic Electric Works |
| Series | P5KS |
| Connector type | Socket, central contact with |
| Needle count | 50 |
| spacing | 0.020"（0.50mm） |
| Row number | 2 |
| Installation Type | Surface Mount Technology |
| Characteristics | - |
| Contact surface treatment | Gold-plated |
| Contact surface treatment thickness | - |
| Combined stacking height | 4mm，5mm，6mm |
| board height | 0.120"（3.05mm） |
Panasonic Connector - Provide an introduction to the Panasonic AXK5S50047YG connector product (series)
Panasonic AXK5S50047YG is a high-precision board-to-board connector with 50 pins, belonging to the P5KS series, and is specifically designed for high-density electronic devices. Its 0.5mm pitch and double-row structure enable efficient and stable signal transmission in compact devices, and is widely used in industrial equipment, consumer electronics, and communication fields. The connector adopts surface mount (SMD) design, suitable for automated production and improving assembly efficiency. Its central contact structure ensures excellent electrical contact performance, while the gold-plated contact process enhances corrosion resistance and conductivity, improving reliability. This model supports 4mm, 5mm, and 6mm mating stack heights, and has a board height of only 3.05mm, suitable for applications with strict space requirements. With excellent manufacturing technology and stable performance, the Panasonic AXK5S50047YG connector is an ideal interconnection solution for high-performance electronic devices.
Panasonic connector - Provide Panasonic AXK5S50047YG connector documentation and media:
| Resource Type | Link |
| Specification Sheet | Please contact the contact person at the bottom of the article page to request. |
Panasonic connector - Provides official Panasonic AXK5S50047YG connector, related specifications and substitute products.
We focus on the spot supply of (Panasonic) brand connectors, committed to providing customers with high-quality and reliable connection solutions. Our products include original genuine and high-performance alternatives, rigorously tested to ensure stability and efficiency. Welcome to contact us through the contact information below the document page!
