EDAC|EDAC Connectors|Canada/Yatex 336 Series Card Edge Connectors are a: Green | 0.156 inch (3.96 mm) pitch | 0.188 inch (4.78 mm) row | 0.720 inch (18.29 mm) insulator height connector. Key features are: 0.156-inch (3.96-millimeter) contact pitch x 0.188-inch (4.78-millimeter) row spacing; accepts 0.062-inch (1.57-millimeter) nominal-thickness printed circuit boards; high-profile insulators, 0.720-inch (18.29-millimeter); 0.062-inch (1.57-millimeter) x 0.031-inch (0.79-millimeter) wirewound Contact terminals; single-row or dual-row configurations; multiple mounting options; accepts contact and contact polarized keys.
1, EDAC | EDAC Connectors | Canada / Yaday Electronics 336 Series Card Edge Connectors main product performance details:
| hallmark | standardize |
| 0.156 inch (3.96 mm) contact spacing x 0.188 inch (4.78 mm) row spacing | Insulator Material: DAP (Diallyl Phthalate, UL-94V-0, Green) |
| Accepts 0.062 inch (1.57 mm) nominal thickness printed circuit boards | Contact Material:Copper Alloy |
| High profile insulator, 0.720 inches (18.29 mm) | Contact plating: gold plating on mating area, tin plating on tail, nickel plating on all bottoms |
| 0.062 in (1.57 mm) x 0.031 in (0.79 mm) wirewound contact terminals | Rated Current:5Amps |
| Single or double row configuration | Contact resistance: 10 milliohms greater |
| Multiple installation options | Dielectric withstand voltage: 1800 V AC rms between adjacent contacts at sea level |
| Accepts contact and contact polarization keys | Insulation resistance: 5000 megohm minimum |
| Certified lead-free | Operating temperature: -65 degrees Celsius to +125 degrees Celsius |
| Insertion force: 16 oz (4.45 Nm) per contact pair greater when tested with a 0.070 in (1.78 mm) thick gauge | |
| Pull-out force: 1 oz (0.28 Nm) minimum per contact pair when tested with a 0.054 in (1.37 mm) thick gauge |
------------------------------------------------------------------------------------------------
2、EDAC|EDAC Connectors|Canada/Yatex 336 Series Card Edge Connectors Main Part Number/Model Number List:
| 336-006-541-601 | 336-007-541-604 | 336-008-541-609 | 336-010-541-603 | 336-011-541-608 |
| 336-006-541-602 | 336-007-541-607 | 336-009-541-601 | 336-010-541-604 | 336-011-541-609 |
| 336-006-541-603 | 336-007-541-608 | 336-009-541-602 | 336-010-541-607 | 336-012-541-601 |
| 336-006-541-604 | 336-007-541-609 | 336-009-541-603 | 336-010-541-608 | 336-012-541-602 |
| 336-006-541-607 | 336-008-541-601 | 336-009-541-604 | 336-010-541-609 | 336-012-541-603 |
| 336-006-541-608 | 336-008-541-602 | 336-009-541-607 | 336-011-541-601 | 336-012-541-604 |
| 336-006-541-609 | 336-008-541-603 | 336-009-541-608 | 336-011-541-602 | 336-012-541-607 |
| 336-007-541-601 | 336-008-541-604 | 336-009-541-609 | 336-011-541-603 | 336-012-541-608 |
| 336-007-541-602 | 336-008-541-607 | 336-010-541-601 | 336-011-541-604 | 336-012-541-609 |
| 336-007-541-603 | 336-008-541-608 | 336-010-541-602 | 336-011-541-607 | 336-012-541-801 |
------------------------------------------------------------------------------------------------
3, Canada EDAC connectors--EDAC|Canada/Yatech Electronics 336 Series Card Edge Connectors This product seller:
Agency sales [Canada EDAC connectors - EDAC | Canada / Yade electronic 336 series card edge connectors] and the contents of the second item in the table list of all (material number / model) connector products; if you want to buy or understand what we can provide connector | harness | cable product solutions, welcome to contact us through the following way.
