JST | Japan JST | JST Terminal | JST Connector DV series 5mm pitch electronic harness is a 5mm pitch double-row connector produced by JST (Japanese Pressure Terminal) Company and UL1007 (wire for general electronic equipment, rated voltage is 300 V); UL1015 (wire for general electronic equipment, rated 600 V); UL1061 (wire for internal cabling and electronic equipment, The electronic wire harness with rated voltage of 300 V is a kind of wire harness product assembled through a unique production process. Our company (World Trade Electronic Products Network) specializes in the production of electronic wire harnesses-JST | Japan JST | JST terminal | JST connector DV series 5mm pitch electronic wire harness. The following picture shows the electronic wire harness (Wire) produced by our company Harness) Some pictures of harness assembly products (pictures are for reference only).
-1. JST | Japan JST | JST terminal | JST connector Schematic diagram, specifications and features of connectors used in DV series 5mm pitch electronic wiring harness:
| Type 1: | Detachable type |
| Type 2: | Crimp type, polarization induced by pin, with locking device |
| Spacing: | 5 |
| Electric current | 5A (AWG#20) |
| Characteristic | With safety locking device |
| Category Name: | Crimp connector (wire-to-board type) |
| Height | 5 |
| Voltage | 250V |
| Thickness: | |
| Description | The spacing of one location is different from the others. This provides polarization to the connector and prevents mis-insertion. * Two-point contact Each terminal has two degaussing zones to ensure a stable and reliable connection. * Mould shell locking method |
-2. JST | Japan JST | JST Terminal | JST Connector DV Series 5mm Pitch Electronic Harness Schematic Diagram and Specifications:
-3. The material number or model of the DV series connector of JST (daily pressure terminal) company used in the electronic harness produced by our company is as follows:
| JST | Japan JST | JST Terminal | JST Connector DV Series Connector Part Number/Model Details | |||
| Sequence | Product name | Family name | RoHS |
| 1 | SDY-01T-P1.6ASV | DV Connector | yes |
| 2 | B06B-DVS-L | DV Connector | yes |
| 3 | S02B-DVS-L | DV Connector | yes |
| 4 | B03B-DVS-L | DV Connector | yes |
| 5 | B02B-DVS-L | DV Connector | yes |
| 6 | DVR-03V-S | DV Connector | yes |
| 7 | DVR-06V-S | DV Connector | yes |
| 8 | B04B-DVS-L | DV Connector | yes |
| 9 | B05B-DVS-L | DV Connector | yes |
| 10 | DVR-05V-S | DV Connector | yes |
| 11 | DVR-04V-S | DV Connector | yes |
| 12 | S03B-DVS-L | DV Connector | yes |
| 13 | DVR-02V-S | DV Connector | yes |
-------------------4、 Electronic Harness-JST | Japan JST | JST Terminal | JST Connector DV Series 5mm Pitch Electronic Harness This Product Manufacturer and Seller: World Trade Electronic Products Network-Production and Sales Provide [Electronic Harness-JST | Japan JST | JST Terminal | JST Connector DV Series 5mm Pitch Electronic Harness] and TE, MOLEX, JST、HRS、JAE、Amphenol Wire composed of electronic wire harness/Teflon wire harness connectors produced by other brands, UL1007 | UL1015 | UL1061 electronic wires and 4.2PH-0.8PH pitch terminal plastic shell connectors Harness harness assembly products; If you want to buy or know what we can offer (Electronic Harness | Wire Harness Assembly Products) solutions, please contact us through the following way.
