Categorization：Replacement Connector
Compatible/Replacement Schentech|Samtec|Shentech Connector|LTMM-115-02-G-D Header Connector is a: Header Connector Through Hole 30 pos 0.079" (2.00mm). 2.00 mm Shrouded Terminal Strip. [Offer Shentai|Samtec|Shentai Connector|LTMM-115-02-G-D Pin Header Connector Replacement].
------------------------------------------------------------------------------------------------
1, Compatible / Alternative Shentai|Samtec|Shentai Connector|LTMM-115-02-G-D header connector products related specifications and parameters:
| makers | Samtec Inc. |
| range | Flex Stack, LTMM |
| wrap | fitting |
| part status | unsold |
| Connector Type | terminal (electrical engineering) |
| Contact type | Male Pin |
| Pitch - Mating | 0.079"（2.00mm） |
| pin position | 30 |
| number of items, etc. in a total | 2 |
| Spacing - Mating | 0.079"（2.00mm） |
| Number of loaded pin positions | possess |
| type | board-to-board |
| shroud | With Shelter - 4 Walls |
| Installation type | vent |
| nock (of a bow) | soldered |
| Fastening type | push-pull |
| Contact Length - Mating | 0.120"（3.05mm） |
| Contact Length - Column | 0.117"（2.97mm） |
| Overall contact length | - |
| Insulation height | 0.190"（4.83mm） |
| Contact shape | square-shaped |
| Contact Finish - Mating | gilt |
| Contact Finish Thickness - Mating | 20.0µin（0.51µm） |
| Contact Finish - Column | gilt |
| Contact Material | phosphor bronze |
| insulating material | Liquid Crystal Polymers (LCP) |
| characterization | keyway |
| operating temperature | -55°C ~ 125°C |
| intrusion protection | - |
| Material flammability class | - |
| Insulation color | ferrous |
| Rated current (amps) | - |
| rated voltage | - |
| Joint Stacking Height | - |
| Contact Finish Thickness - Column | 3.00µin（0.076µm） |
| appliance | - |
| Basic Product Number | LTMM-115 |
------------------------------------------------------------------------------------------------
2, Compatible/Replacement for Shentai|Samtec|Shentai Connector|LTMM-115-02-G-D Header Connector Product Specification:
------------------------------------------------------------------------------------------------
3, Compatible / Replacement Shentai | Samtec | Shentai Connectors | LTMM-115-02-G-D header connector product number / model list:
| ISS1-02 | ISS1-13 | ISSM-05 | ISSM-16 |
| ISS1-03 | ISS1-14 | ISSM-06 | ISSM-17 |
| ISS1-04 | ISS1-15 | ISSM-07 | ISSM-18 |
| ISS1-05 | ISS1-16 | ISSM-08 | ISSM-19 |
| ISS1-06 | ISS1-17 | ISSM-09 | ISSM-20 |
| ISS1-07 | ISS1-18 | ISSM-10 | ISSM-21 |
| ISS1-08 | ISS1-19 | ISSM-11 | ISSM-22 |
| ISS1-09 | ISS1-20 | ISSM-12 | ISSM-23 |
| ISS1-10 | ISSM-02 | ISSM-13 | ISSM-24 |
| ISS1-11 | ISSM-03 | ISSM-14 | ISSM-25 |
| ISS1-12 | ISSM-04 | ISSM-15 |
-------------------------------------------------------------------------------------------------
4、Pin Header Connector - Provide compatible Samtec|LTMM-115-02-G-D pin header connector replacement This product seller:
We are a professional distributor of [Header Connectors - Compatible with Samtec|LTMM-115-02-G-D Header Connector Replacement] and specialized in distributing/manufacturing/selling various kinds of {Connectors|Wiring Harnesses|Wire Harnesses|Wire Cables}; If you want to buy or know what connectors, harnesses or wire harnesses we have to offer, please feel free to contact us through the following ways.
